Sheet

GP GRADE

1. CAST ACRYLIC SHEET Production Introduction

Stimex Corp. supplies general purpose grade Cast Acrylic sheet in various colors as clear and matte sheet.

Characteristics

  • Crystal clear
  • Light in weight
  • Very easy to work, similar to hard wood
  • Excellent thermal conductivity

Density : 1.19

  • Excellent light transmittance
  • Good weather resistance
  • Good chemical resistance
  • Various colors available

Light transmittance: 92%

Application

  • Architectural decoration, all kinds of furniture material.
  • Advertisement signboard, art illumination equipment.
  • Door, window, lampshade and corrugated roof.
  • Mechanical cover, scale board for electric appliance, insulation material.
  • Fabricated products such as picture frame, stationery, jewelry box, etc.

Standard Spec

  • Thickness: 2.0mm ~ 50.0mm or more.
  • Spec: 3' x 6', 4' x 6', 4' x 8', 5' x 8', 6' x 8', 2M x 3M …etc.
  • Common Specs:

Clear Sheet

Size Thickness availability Size Thickness availability
36" x  72" 2.0 ~ 20.0mm 51" x 100" 2.0 ~ 12.0mm
50" x  74" 2.0 ~ 25.0mm 60" x  96" 2.8 ~ 12.0mm
48" x  72" 2.0 ~ 50.0mm 62" x  98" 2.8 ~  9.0mm
48" x  96" 2.0 ~ 50.0mm 72" x  96" 2.8 ~ 12.0mm
50" x  98" 2.0 ~ 30.0mm 74" x  98" 2.8 ~  9.0mm

Matt Sheet

Size Thickness availability Size Thickness availability
50" x  74" 2.0 ~ 13.0mm 48" x  96" 2.0 ~  9.0mm

Thickness tolerance

2.0mm: ± 12%, 2.5 ~10mm: ± 10%, 12 ~ 20mm: ± 8%, 25 ~ 44mm: ± 6%, 50mm: ± 7%

2. Extruded Acrylic Sheet

Stimex Corp. supplies general purpose grade Extruded Acrylic sheet as well.

  • Density: 1.20
  • Available thickness: 1.5mm ~ 6.0mm
  • Door, window, lampshade and corrugated roof.
  • Available width: 915mm ~ 1320mm
  • Available colors: clear & opal white
